Key Features
- Bluetooth to 0-10V signal PIR sensor controller,Bluetooth® mesh network
- Built-in 20mA 0-10V signal output
- Mesh network, which has a much longer control distance, transmits received signals to neighboring devices
- All devices on 0-10V line are broadcast controlled by mobile application
- Supporting our kinetic energy switches and EnOcean switches EWSSB and EWSDB
- In typical indoor environment, the range for wireless communication is 20m to 25m . Actual range is dependent on field installation
- On-board antenna
- Standby power consumption less than 0.5W,meet latest ERP regulation
- Available with Magnetic reset (Touch the top part of sensor for 5 seconds)
- Waterproof grade: IP20
- 5 Years Warranty
Specifications
| Part No. | Input Voltage | Input Signal |
Output Signal
|
0/1-10V Output Current
|
Sensor Type
|
Detection Range |
|---|---|---|---|---|---|---|
| SR-SV9032A-PIR-V |
12-24VDC
|
Silvair Bluetooth
|
0/1-10V
|
Max. 20mA
|
PIR Sensor
|
φ5m@2.5m |
Product Dimension
Wiring Diagram
