This Bluetooth 0-10V sensor-less controller features a Bluetooth® mesh network for extended range and seamless signal transmission. It allows mobile app broadcast control of all 0-10V devices, supports kinetic and EnOcean switches, and offers a plug & play 3.5mm audio-jack interface. With magnetic reset, on-board antenna, IP65 waterproof rating for outdoor use, and a 5-year warranty, it delivers reliable, easy-to-install smart lighting control for diverse applications.
Features
• Bluetooth to 0-10V sensor-less controller , Bluetooth® mesh network
• Mesh network, which has a much longer control distance, transmits received signals to neighboring devices
• All devices on 0-10V line are broadcast controlled by mobile application
• Supporting our kinetic energy switches and EnOcean switches EWSSB and EWSDB
• 3.5mm Audio-Jack interface （Plug&Play）
• Available with Magnetic reset (touch the top part of sensor for 5 seconds)
• On-board antenna
• Waterproof grade: IP65, suitable for outdoor luminaries
• 5 years warranty
Specifications
| Part No. | Input Voltage | Input signal | Output, 0/1-10V | Note |
|---|---|---|---|---|
| SR-BL9033J-V | 12-24VDC |
Bluetooth
|
Max. 20mA | Signal Converter |
Product Dimension
Wiring Diagram
