This Bluetooth to 0-10V sensor controller is designed for Bluetooth® mesh networks, enabling long-range wireless communication by relaying signals between neighboring devices. It supports autonomous sensor-based control and allows broadcast control of all devices on the 0-10V line via a mobile application. Compatible with kinetic energy switches and EnOcean EWSSB/EWSDB switches, it features a ZHAGA Book 18 socket and convenient magnetic reset by touching the top of the sensor for 5 seconds. Built with an on-board antenna and IP65 waterproof rating, it is ideal for outdoor luminaires and comes with a 5-year warranty.
Key Features
• Bluetooth to 0-10V sensor controller, Bluetooth® mesh network
• Mesh network, which has a much longer control distance, transmits received signals to neighboring devices
• All devices on 0-10V line are broadcast controlled by mobile application
• Suppors our kinetic energy switches and EnOcean switches EWSSB and EWSDB
• Autonomos sensor-based control
• ZHAGA Book 18 socket
• Available with Magnetic reset (touch the top part of sensor for 5 seconds)
• On-board antenna
• Waterproof grade: IP65, suitable for outdoor luminaries
• 5 years warranty
Specifications
| Part No. | Input Voltage | Input Signal | Output Signal | 0-10V Output Current |
Note
|
|---|---|---|---|---|---|
| SR-SV9033A-V |
12-24VDC
|
Silvair Bluetooth
|
0/1-10V
|
Max. 20mA
|
Signal Converter |
Wiring Diagram
Dimension
