Key Features
- Bluetooth® mesh LED controller. Max.power 48-96W per channel
- Enables to control ON/OFF, light intensity, tunable white type of LED fixtures
- Controlled through Silvair Commissioning tools
- Mesh network, which has a much longer control distance, transmits received signals to neighboring devices
- Supporting our kinetic energy switches and EnOcean switches EWSSB and EWSDB
- In typical indoor environment, the typical range for wireless communication is 20m to 25m . Actual range is dependent on field installation.
- On-board antenna
- Over-temperature/ Over-load/ Over-voltage/ Short-circuit protection.
- Waterproof grade: IP20
- 5 Years Warranty
Specifications
| Part No. | Input Voltage | Output Current | Output Power | Output type | Dimension (mm) |
|---|---|---|---|---|---|
| SR-BL1029-SVT | 12-24VDC | 4CH, 4A/CH | 48-96W | Constant Voltage |
145×46.5×16
|
Wiring Diagram
Product Dimension
