SR-2833RGB is a RF wireless push remote controller which is designed control RGB or RGBW LEDs with both switch and brightness adjustment function. It is a single zone RGB or RGBW controller with 1 built-in dynamic changing pattern and 10 static colors. Color changing speed is adjustable when played. Smooth and accurate color tone adjustment can be achieved by buttons. The push remote can be wall mounted or stuck on wall easily by 3M glue.
Key Features
- RF wireless push remote
- Single zone remote control with 1 built-in changing pattern and 10 static colors
- Switch on/off and brigtness adjustment of RGB/RGBW
- Smooth and accurate color tone adjustment by buttons
- Easy installation
Remote
| Part No. | Operation Voltage | Operation Frequency | Dimension (mm) | Remarks |
|---|---|---|---|---|
| SR-2833RGB | 3VDC CR2430 Battery | 434MHz/869.5MHz | 86*86*13.8 | RF Wireless |
Compatible Receiver
| Part No. | Input Voltage | Output Current | Output Power | Output type | Dimension (mm) |
|---|---|---|---|---|---|
| SR-1009FA | 12-36VDC | 4CH, 5A/CH | 240-720W | Constant Voltage | 46*178*18 |
| SR-1009FA3 | 12-36VDC | 4CH, 0.35/CH | 16.8-50.4W | Constant Current | 46*178*18 |
| SR-1009FA7 | 12-36VDC | 4CH, 0.7A/CH | 33.6-100.8W | Constant Current | 46*178*18 |
| SR-1009EA | 12-36VDC | 4CH, 8A/CH | 384-1152W | Constant Voltage | 58*168*28 |
Installation
Receiver Wiring Diagram
