Dual Color Rotary RF LED Controller SR-2836CCT

Rotary dual color LED controller SR-2836CCT is a RF wall mounted control with switch, color temperature and brightness adjustment functions for dual color (warm white and cool white) LEDs. The rotary dimmer controller features accurate and smooth color temperature adjustment as well as dim your lights from 0.1% to 100% without any flickering.

Stok kodu: SR-2836CCT Kategoriler:

Rotary dual color LED controller SR-2836CCT is a RF wall mounted control with switch, color temperature and brightness adjustment functions for dual color (warm white and cool white) LEDs. The rotary dimmer controller features accurate and smooth color temperature adjustment as well as dim your lights from 0.1% to 100% without any flickering. Double clicking the rotary knob enables the controller to switch from brightness dimming to color temperature adjustment. Each controller can control 1 zone with endless receivers. Available in standard Europe size and US size as well, the dimmer can be suitable for electric wall boxes from different areas.

Başlıca Özellikler

  • RF wall mounted control with switch, color temperature and brightness adjustment functions for dual color (warm white and cold white) LEDs.
  • Reliable and stable switch and dimming control function, control range up to 20M.
  • Battery in the remote is with long life span. It normally can use for 5 years.
  • Switch on/off of lighting slowly, without any flash, meet the comfort of human eyes.
  • Dimming range 0.1-100%.
  • Double clicking the rotary knob enables the controller to switch from brightness dimming to color temperature adjustment.
  • Receivers can work with power repeater to expand the output power unlimitedly.
  • Enable to control 1 zones separately, each zone can be set endless receivers, each receiver maximally be controlled by 8 different remotes.
  • Rotary adjustment, wall mounted panel
  • Italian/Australian, US in-wall size available.



Uzak

Parça No. Çalışma Gerilimi Çalışma Frekansı Boyut (mm) Notlar
SR-2836CCT 3VDC 434MHz/869.5MHz 86*86*41 RF Kablosuz
SR-2836CCT(IT) 3VDC 434MHz/869.5MHz 120*80*41 RF Kablosuz
SR-2836CCT(US) 3VDC 916,5 MHz 75*120*41 RF Kablosuz











Uyumlu Alıcı

Parça No. Giriş Gerilimi Çıkış Akımı Çıkış Gücü Çıktı türü Boyut (mm)
SR-1009FA 12-36VDC 4CH, 5A/CH 240-720W Sabit Gerilim 46*178*18
SR-1009EA 12-36VDC 4CH, 8A/CH 384-1152W Sabit Gerilim 58*168*28
SR-1009FA3 12-36VDC 4CH, 0.35A/CH 16.8-50.4W Sabit Akım 46*178*18
SR-1009FA7 12-36VDC 4CH, 0.7A/CH 33,6-100,8 W Sabit Akım 46*178*18













Kurulum

Installation



Alıcı Kablolama Şeması

Receiver Wiring Diagram for Single Unit

Kullanım Kılavuzu (PDF)
